ABS is a strong, impact-resistent thermoplastic known for it’s durability and heat resistance. It is ideal for functional parts, mechanical components, and high-stress applications. ABS requires controlled printing conditions due to it’s tendency to warp therefore, overlal part dimensions are limited.

FDM
ABS
More info
×
ABS
Available Colours
Swatch
Colour Name
Black
White
Mechanical Properties
Label
Value
Test Method
Tensile Strength at Yield
460 kg/cm2
ASTM D638
Elongation at Break
10%
ASTM D638
Flexural Strength
740 kg/cm2
ASTM D790
Heat Deflection Temperature
85°C
ASTM D648
Tolerance
Label
Value
Tolerance
± 0.15%
Lower Limit
Label
Value
Lower Limit
± 0.2mm
Layer Height
Label
Value
Layer Height
100 microns, 200microns, 300 microns
Downloads
File Name
Download
ABS Technical Data Sheet
